Hydrogel's water-based gel forms a cooling shield, enhancing fire suppression as temperatures rise.
Foamed Hydrogel clings to hot surfaces and floats on fuels, offering comprehensive fire coverage.
Water content in Hydrogel cools fire temperatures effectively, preventing re-ignition.
Clay particles in Hydrogel create a robust oxygen barrier, eliminating the need for harmful chemicals.
| MODEL | KFLIHQ-1 | MODEL | KFLIHQ-1 |
|---|---|---|---|
| Capacity | 1 Ltr | Design | Nozzle |
| Fire Rating | 3A | Height (Approx.) | 325 mm |
| Diameter (Approx.) | 86 ± 5 mm | Average Discharge time | 25 Sec |
| Average Range of throw | 1.5 - 2 m | Average % Discharge | 85% |
| Operating Temperature | +5° to +60° C | Service/Max. service/Test Pressure | 15/18/35 bar |
| Expelling Agent | Nitrogen (UHP) | Empty Weight (Approx.) | 1.2 kg |
| Full Weight (Approx.) | 2.2 kg | Shipping Weight (Approx.) | 2.5 kg |
| Mounting Bracket | VEHICLE MOUNTED/WALL MOUNTED |
| MODEL | KFLIHQ-2 | MODEL | KFLIHQ-2 |
|---|---|---|---|
| Capacity | 2 Ltr | Design | Nozzle |
| Fire Rating | 3A | Height (Approx.) | 380 mm |
| Diameter (Approx.) | 106± 5 mm | Average Discharge time | 50 sec |
| Average Range of throw | 1.5 - 2 m | Average % Discharge | 85% |
| Operating Temperature | +5° to +60° C | Service/Max. service/Test Pressure | 15/18/35 bar |
| Expelling Agent | Nitrogen (UHP Grade) | Empty Weight (Approx.) | 1.5 kg |
| Full Weight (Approx.) | 3.5 kg | Shipping Weight (Approx.) | 3,9 kg |
| Mounting Bracket | VEHICLE MOUNTED/WALL MOUNTED |
| MODEL | KFLIHQ-4 | MODEL | KFLIHQ-4 |
|---|---|---|---|
| Capacity | 4 Ltr | Design | Hose with Nozzle |
| Fire Rating | 3A | Height (Approx.) | 490 mm |
| Diameter (Approx.) | 140± 5 mm | Average Discharge time | 80 Sec |
| Average Range of throw | 1.5 - 2 m | Average % Discharge | 85% |
| Operating Temperature | +5° to +60° C | Service/Max. service/Test Pressure | 15/18/35 bar |
| Expelling Agent | Nitrogen (UHP Grade) | Empty Weight (Approx.) | 2.7 kg |
| Full Weight (Approx.) | 6.7 kg | Shipping Weight (Approx.) | 7.1 kg |
| Mounting Bracket | WALL MOUNTED |
| MODEL | KFLIHQ-6 | MODEL | KFLIHQ-6 |
|---|---|---|---|
| Capacity | 6 Ltr | Design | Hose with Nozzle |
| Fire Rating | 3A | Height (Approx.) | 530 mm |
| Diameter (Approx.) | 150± 5 mm | Average Discharge time | 120 Sec |
| Average Range of throw | 1.5 - 2 m | Average % Discharge | 85% |
| Operating Temperature | +5° to +60° C | Service/Max. service/Test Pressure | 15/18/35 bar |
| Expelling Agent | Nitrogen (UHP Grade) | Empty Weight (Approx.) | 3.6 kg |
| Full Weight (Approx.) | 9.6 kg | Shipping Weight (Approx.) | 10 kg |
| Mounting Bracket | WALL MOUNTED |
| MODEL | KFLIHQ-9 | MODEL | KFLIHQ-9 |
|---|---|---|---|
| Capacity | 9 Ltr | Design | Hose with Nozzle |
| Fire Rating | 13A | Height (Approx.) | 575 mm |
| Diameter (Approx.) | 180 ± 5 mm | Average Discharge time | 170 Sec |
| Average Range of throw | 1.5 - 2 m | Average % Discharge | 85% |
| Operating Temperature | +5° to +60° C | Service/Max. service/Test Pressure | 15/18/35 bar |
| Expelling Agent | Nitrogen (UHP Grade) | Empty Weight (Approx.) | 4.9 kg |
| Full Weight (Approx.) | 13.9 kg | Shipping Weight (Approx.) | 14.4 kg |
| Mounting Bracket | WALL MOUNTED |
